Last major update issued on August 16, 2015 at 02:40 UT.

Charts (* = updated daily) Data and archive
  Solar wind (*) Solar and geomagnetic data - last month (*)
  Electron fluence (*) Archived daily reports and monthly data from 2003.01 (August 1, 2015)
Solar cycle Solar cycles 23-24 (August 1, 2015) Historical solar and geomagnetic data charts 1954-2006 (April 5, 2007)
  Cycle 24 progress (August 1, 2015) Noon SDO sunspot count 1K Reference: 4K (large file) (*)
  Solar cycles 1-24 (July 17, 2015) POES auroral activity level October 2009 - December 2012
  Comparison of cycles 21, 22, 23 and 24 (August 1, 2015) 3rd SSN Workshop, Tucson, 2013
  Comparison of cycles 12, 13, 14, 16 and 24 (August 1, 2015) 4th SSN Workshop, Locarno, 2014
  Solar polar fields vs solar cycles (July 18, 2015)

Recent activity

The geomagnetic field was quiet to major storm on August 15. Solar wind speed at SOHO ranged between 332 and 507 km/s. A solar wind shock was observed at SOHO at 07:49 UT, the arrival of the CME observed on August 12.

Solar flux at 20h UTC on 2.8 GHz was 89.4 (decreasing 10.0 over the last solar rotation). The 90 day 10.7 flux at 1 AU was 114.1. The Potsdam WDC planetary A index was 38 (STAR Ap - based on the mean of three hour interval ap indices: 38.4). Three hour interval K indices: 22366534 (planetary), 22465533 (Boulder).

The background x-ray flux is at the class B2 level.

At the time of counting spots (see image time), spots were observed in 4 active regions using 2K resolution (SN: 83) and 3 active regions using 1K resolution (SN: 53) SDO images on the visible solar disk.

Region 12400 [N18W18] decayed slowly and quietly.
Region 12401 [S11E24] gained a few spots and produced the only C class event of the day.

Spotted regions not numbered (or interpreted differently) by SWPC:
S4689 [S23W21] reemerged with penumbra spots.
S4691 [N17E02] was quiet and stable.

C2+ flares:

Magnitude Peak time (UTC) Location AR Recorded by Comment


Flare activity (SDO/EVE/ESP XRS-B proxy)

Coronal mass ejections (CMEs)

August 13-15: No obviously Earth directed CMEs were observed.

Coronal holes

[Coronal hole history (since October 2002)]
[Compare today's report to the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago]

A recurrent trans equatorial coronal hole (CH682) was in an Earth facing position on August 12-13. Geomagnetic disturbances associated with CH682 over previous rotations have been weak. An extension of a northern hemisphere coronal hole (CH683) will likely rotate across the central meridian on August 15-17. A co-rotating interaction region may be associated with CH683 and could cause a geomagnetic disturbance on August 17-19.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along paths north of due west over upper middle latitudes is poor. Propagation on long distance northeast-southwest paths is fair.

Forecast

The geomagnetic field is expected to be quiet to active on August 16 with a chance of minor storm intervals due to CME effects and quiet to unsettled on August 17. A possible co-rotating interaction region associated with CH683 could cause unsettled to active conditions on August 18-20.

Coronal holes (1) Coronal mass ejection (2) M and X class flares (3)


1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-30% probability, Yellow: 30-70% probability, Red: 70-100% probability.

Active solar regions


(Click on image for 2K resolution) Compare to the previous day's image.

0.5K image

When available the active region map has a coronal hole polarity overlay where red (pink) is negative and blue is positive.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SWPC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SWPC or where SWPC has observed no spots. SWPC active region numbers in the table below and in the active region map above are the historic SWPC/USAF numbers.

Active region Date numbered
detected
Spot count Location at midnight Area Classification SDO / HMI 4K continuum
image with magnetic polarity overlays
Comment
SWPC Magnetic
(SDO)
SWPC STAR Current Previous
2K 1K
12398 2015.08.06
2015.08.07
      N16W50         location: N18W38
12399 2015.08.10
2015.08.11
      S16W56
12400 2015.08.11 5 8 4 N18W18 0030 CAO CRO
12401 2015.08.12
2015.08.13
8 25 16 S11E22 0030 CRI DRI

reversed polarities

S4686 2015.08.12       S02W48
S4687 2015.08.13       S07E28
S4688 2015.08.13       N20W08
S4689 2015.08.13   2   S23W24 0005   AXX
S4690 2015.08.14       N09E55
S4691 2015.08.14   8 3 N16E01 0020   AXX images/AR_S4691_20150815_2345.png
S4692 2015.08.14       S07W12
Total spot count: 13 43 23
Sunspot number: 33 83 53  (total spot count + 10 * number of spotted regions)
Weighted SN: 21 49 29  (Sum of total spot count + classification weighting for each AR. Classification weighting: X=0, R=3, A/S=5, H/K=10)
Relative sunspot number (Wolf number): 36 46 45 k * (sunspot number)
As of July 1, 2015: k = 1.1 for SWPC, k = 0.55 for MSN 2K, k = 0.85 for MSN 1K (MSN=Magnetic Sunspot Number)

Monthly solar cycle data

Month Average solar flux International sunspot number
(WDC-SILSO) (4)
Smoothed sunspot number (4) Average ap
(3)
Measured 1 AU
2014.02 170.3
(cycle peak)
166.3 146.1 (cycle peak) 110.5 (+1.2) 10.70
2014.03 149.9 148.5 128.7 114.3 (+3.8) 4.88
2014.04 143.9 144.8 112.5 116.4 (+2.1) (solar max) 7.88
2014.05 129.7 132.9 112.5 115.0 (-1.4) 5.75
2014.06 122.0 125.8 102.9 114.1 (-0.9) 6.72
2014.07 137.4 141.8 100.2 112.6 (-1.5) 4.50
2014.08 124.7 127.9 106.9 108.3 (-4.3) 7.71
2014.09 146.6 148.1 130.0 101.9 (-6.4) 9.78
2014.10 153.4 152.9 90.0 97.4 (-4.5) 8.96
2014.11 154.8 151.4 103.6 95.0 (-2.4) 9.33
2014.12 158.7 153.8 112.9 92.6 (-2.4) 11.24
2015.01 141.9 137.3 93.0 89.8 (-2.8) 9.46
2015.02 129.1 126.0 66.7 (86.8 projected, -3.0) 9.92
2015.03 125.9 124.6 54.5 (83.1 projected, -3.7) 16.14
2015.04 128.8 129.7 78.0 (79.8 projected, -3.3) 10.73
2015.05 120.0 122.6 90.0 (77.4 projected, -2.4) 8.29
2015.06 122.3 126.1 68.3 (73.9 projected, -3.5) 13.15
2015.07 107.0 110.8 66.4 (70.2 projected, -3.7) 8.8
2015.08 (106.0)   33.2 (2A) / 68.5 (2B) / 73.3 (2C) (69.0 projected, -1.2) (9.9)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2A) Current impact on the monthly sunspot number based on the Boulder (NOAA/SWPC) sunspot number (accumulated daily sunspots / month days).
2B) Boulder SN current month average to date.
2C) STAR SDO 1K Wolf number 30 day average.
3) Running average based on the quicklook and definitive Potsdam WDC ap indices. Values in red are based on the definitive international GFZ Potsdam WDC ap indices.
4) Updated to new data set from WDC-SILSO on July 1, 2015

This report has been prepared by Jan Alvestad. It is based on the analysis of data from whatever sources are available at the time the report is prepared. All time references are to Universal Time. Comments and suggestions are always welcome.

SDO images are courtesy of NASA/SDO and the AIA, EVE, and HMI science teams.
