The geomagnetic field was very quiet on August 14. Solar wind speed at SOHO ranged between 289 and 380 km/s.
Solar flux at 20h UTC on 2.8 GHz was 93.2 (decreasing 2.8 over the last solar rotation). The 90 day 10.7 flux at 1 AU was 114.4. The Potsdam WDC planetary A index was 2 (STAR Ap - based on the mean of three hour interval ap indices: 2.3). Three hour interval K indices: 00011011 (planetary), 00112312 (Boulder).
The background x-ray flux is at the class B2 level.
At the time of counting spots (see image time), spots were observed in 6 active regions using 2K resolution (SN: 104) and 4 active regions using 1K resolution (SN: 64) SDO images on the visible solar disk.
Region 12398 [N18W25] was quiet and stable.
Region 12400 [N18W05] decayed slowly and quietly.
Region 12401 [S11E38] lost the magnetic delta early in the day after
producing 4 low level C flares.
Spotted regions not numbered (or interpreted differently) by SWPC:
New region S4690 [N09E68] emerged with a penumbra spot.
New region S4691 [N09E06] was observed with penumbra spots.
New region S4692 [S07E01] emerged with a penumbra spot.
C2+ flares:
| Magnitude | Peak time (UTC) | Location | AR | Recorded by | Comment |
August 11, 13: No obviously Earth directed CMEs were observed.
August 12: A partial halo CME was observed after a complex chain of filament eruptions in the southwest quadrant. The first eruption began after 14h UTC and
likely triggered a second eruption close to CH682.
[Coronal hole
history (since October 2002)]
[Compare today's report to the situation one solar rotation ago:
28 days ago
27 days ago
26 days ago]
A recurrent trans equatorial coronal hole (CH682) was in an Earth facing position on August 12-13. Geomagnetic disturbances associated with CH682 over previous rotations have been weak. An extension of a northern hemisphere coronal hole (CH683) will likely rotate across the central meridian on August 15-17. A co-rotating interaction region may be associated with CH683 and could cause a geomagnetic disturbance on August 17-19.
Long distance low and medium frequency (below 2 MHz) propagation along paths north of due west over upper middle latitudes is poor. Propagation on long distance northeast-southwest paths is poor.
The geomagnetic field is expected to be quiet on August 15 with a chance of unsettled and active intervals late in the day should due to the possible arrival of the August 12 CME. Quiet to active conditions are possible on August 16 due to CME effects. Weak effects from CH682 are possible from late on August 15 until August 17. A possible co-rotating interaction region associated with CH683 could cause unsettled to active conditions on August 18-20.
| Coronal holes (1) | Coronal mass ejection (2) | M and X class flares (3) |
1) Effects from a coronal hole could reach Earth within the
next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48
hours.
Green: 0-30% probability, Yellow: 30-70% probability, Red: 70-100% probability.
(Click on image for 2K resolution)
Compare to the previous day's image.
When available the active region map has a coronal hole polarity overlay where red (pink) is negative and blue is positive.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SWPC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SWPC or where SWPC has observed no spots. SWPC active region numbers in the table below and in the active region map above are the historic SWPC/USAF numbers.
| Active region | Date numbered detected |
Spot count | Location at midnight | Area | Classification | SDO / HMI 4K continuum image with magnetic polarity overlays |
Comment | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| SWPC | Magnetic (SDO) |
SWPC | STAR | Current | Previous | ||||||
| 2K | 1K | ||||||||||
| 12395 | 2015.08.02 2015.08.03 |
N12W84 | |||||||||
| 12396 | 2015.08.03 | 3 | S18W91 | 0040 | CAO |
 |
rotated out of view | ||||
| 12398 | 2015.08.06 2015.08.07 |
4 | 1 | N16W36 | 0006 | BXO |
 |
 |
location: N18W25 | ||
| S4679 | 2015.08.09 | S17W55 | |||||||||
| 12399 | 2015.08.10 2015.08.11 |
S16W42 | |||||||||
| 12400 | 2015.08.11 | 5 | 13 | 8 | N17W05 | 0050 | CAO | DRO |
 |
 |
|
| S4683 | 2015.08.12 | N03W58 | |||||||||
| 12401 | 2015.08.12 2015.08.13 |
8 | 21 | 13 | S12E37 | 0070 | CAI | DRI |
 |
 |
reversed polarities |
| S4686 | 2015.08.12 | S02W35 |
 |
||||||||
| S4687 | 2015.08.13 | S07E41 |
 |
||||||||
| S4688 | 2015.08.13 | N20E05 |
 |
||||||||
| S4689 | 2015.08.13 | S23W12 |
 |
||||||||
| S4690 | 2015.08.14 | 1 | N09E68 | 0001 | AXX |
 |
|||||
| S4691 | 2015.08.14 | 4 | 2 | N09E06 | 0010 | AXX |
 |
||||
| S4692 | 2015.08.14 | 1 | S07E01 | 0002 | AXX |
 |
|||||
| Total spot count: | 16 | 44 | 24 | ||||||||
| Sunspot number: | 46 | 104 | 64 | (total spot count + 10 * number of spotted regions) | |||||||
| Weighted SN: | 31 | 50 | 30 | (Sum of total spot count + classification weighting for each AR. Classification weighting: X=0, R=3, A/S=5, H/K=10) | |||||||
| Relative sunspot number (Wolf number): | 51 | 57 | 54 | k * (sunspot number) As of July 1, 2015: k = 1.1 for SWPC, k = 0.55 for MSN 2K, k = 0.85 for MSN 1K (MSN=Magnetic Sunspot Number) |
|||||||
| Month | Average solar flux | International sunspot number (WDC-SILSO) (4) |
Smoothed sunspot number (4) | Average
ap (3) |
|
|---|---|---|---|---|---|
| Measured | 1 AU | ||||
| 2014.02 | 170.3 (cycle peak) |
166.3 | 146.1 (cycle peak) | 110.5 (+1.2) | 10.70 |
| 2014.03 | 149.9 | 148.5 | 128.7 | 114.3 (+3.8) | 4.88 |
| 2014.04 | 143.9 | 144.8 | 112.5 | 116.4 (+2.1) (solar max) | 7.88 |
| 2014.05 | 129.7 | 132.9 | 112.5 | 115.0 (-1.4) | 5.75 |
| 2014.06 | 122.0 | 125.8 | 102.9 | 114.1 (-0.9) | 6.72 |
| 2014.07 | 137.4 | 141.8 | 100.2 | 112.6 (-1.5) | 4.50 |
| 2014.08 | 124.7 | 127.9 | 106.9 | 108.3 (-4.3) | 7.71 |
| 2014.09 | 146.6 | 148.1 | 130.0 | 101.9 (-6.4) | 9.78 |
| 2014.10 | 153.4 | 152.9 | 90.0 | 97.4 (-4.5) | 8.96 |
| 2014.11 | 154.8 | 151.4 | 103.6 | 95.0 (-2.4) | 9.33 |
| 2014.12 | 158.7 | 153.8 | 112.9 | 92.6 (-2.4) | 11.24 |
| 2015.01 | 141.9 | 137.3 | 93.0 | 89.8 (-2.8) | 9.46 |
| 2015.02 | 129.1 | 126.0 | 66.7 | (86.8 projected, -3.0) | 9.92 |
| 2015.03 | 125.9 | 124.6 | 54.5 | (83.1 projected, -3.7) | 16.14 |
| 2015.04 | 128.8 | 129.7 | 78.0 | (79.8 projected, -3.3) | 10.73 |
| 2015.05 | 120.0 | 122.6 | 90.0 | (77.4 projected, -2.4) | 8.29 |
| 2015.06 | 122.3 | 126.1 | 68.3 | (73.9 projected, -3.5) | 13.15 |
| 2015.07 | 107.0 | 110.8 | 66.4 | (70.2 projected, -3.7) | 8.8 |
| 2015.08 | (107.1) | 32.1 (2A) / 71.1 (2B) / 74.2 (2C) | (69.0 projected, -1.2) | (7.9) | |
1) Running average based on the daily 20:00 UTC observed solar flux value at
2800 MHz.
2A) Current impact on the monthly sunspot number based on the Boulder
(NOAA/SWPC) sunspot number (accumulated daily sunspots / month days).
2B)
Boulder SN current month average to date.
2C) STAR SDO 1K Wolf number 30 day
average.
3) Running average based on the quicklook and definitive Potsdam WDC ap
indices. Values in red are based on the definitive
international
GFZ Potsdam
WDC
ap indices.
4) Updated to new data set from WDC-SILSO on July 1, 2015
This report has been prepared by Jan Alvestad. It is based on the analysis of data from whatever sources are available at the time the report is prepared. All time references are to Universal Time. Comments and suggestions are always welcome.
SDO images are courtesy of NASA/SDO and the AIA, EVE, and HMI science teams.
