The geomagnetic field was quiet to unsettled on April 22. Solar wind speed at SOHO ranged between 457 and 560 km/s.
Solar flux at 20h UTC on 2.8 GHz was 150.3 (increasing 14.2 over the last solar rotation). The 90 day 10.7 flux at 1 AU was 129.0. The Potsdam WDC planetary A index was 8 (STAR Ap - based on the mean of three hour interval ap indices: 8.4). Three hour interval K indices: 22322122 (planetary), 22433323 (Boulder).
The background x-ray flux is at the class B9 level.
At the time of counting spots (see image time), spots were observed in 19 active regions using 2K resolution (SN: 345) and 16 active regions using 1K resolution (SN: 235) SDO images on the visible solar disk.
Region 12321 [N11W73] was quiet and stable.
Region 12324 [N18W46] decayed slowly producing a
few low level C flares.
Region 12325 [N05W38] was mostly quiet and stable. Minor polarity
intermixing was observed.
Region 12327 [S09E04] was quiet and stable.
Region 12330 [N15E08] was quiet and stable.
Region 12331 [S10W05] developed slowly and was mostly quiet.
Region 12332 [S14W30] decayed slowly and quietly.
New region 12333 [N20E65] rotated into view on April 21 and was numbered
by SWPC the next day.
Spotted regions not numbered (or interpreted
differently) by SWPC:
S4367 [N08W71] decayed slowly and quietly.
S4383 [S10W15] was quiet and stable.
S4389 [S22E10] was quiet and stable.
S4398 [N10W12] developed slowly and quietly.
S4400 [N08E19] was quiet and stable.
S4404 [N08E52] was quiet and stable.
S4406 [S11W39] decayed slowly and quietly.
New region S4407 [N18E40] was observed with
penumbra spots.
New region S4408 [N20W67] emerged quickly with several spots. C flares
are possible.
New region S4409 [S03E42] was observed with a penumbra spot.
New region S4410 [N23E13] emerged with penumbra spots.
| Magnitude | Peak time (UTC) | Location | AR | Recorded by | Comment |
| C2.3 | 01:15 | S4392 | GOES15 | attributed to AR 12325 by SWPC | |
| C3.7/1N | 01:44 | N23W32 | 12324 | GOES15 | |
| C4.6 | 02:07 | S4392 | GOES15 | attributed to AR 12325 by SWPC | |
| C5.5 | 02:18 | S4392 | SDO/EVE, Learmonth | ||
| C2.8 | 03:05 | S4392 | GOES15 | attributed to AR 12333 by SWPC | |
| C4.0 | 03:20 | S4392 | SDO/EVE | ||
| C4.1 | 03:25 | N22W35 | 12324 | GOES15 | |
| C2.8 | 04:51 | 12324 | SDO/EVE | ||
| C2.3 | 06:11 | S4392 | GOES15 | ||
| C2.3 | 07:11 | S10E17 | 12327 | GOES15 | |
| C3.8 | 08:06 | N21W37 | 12324 | GOES15 | |
| M1.1 | 08:44 | N10W90 | S4392 | GOES15 | attributed to AR 12332 by SWPC |
| C6.8 | 09:18 | 12324 | SDO/EVE, San Vito |
April 20-22: No obviously Earth directed CMEs were observed.
[Coronal hole
history (since October 2002)]
[Compare today's report to the situation one solar rotation ago:
28 days ago
27 days ago
26 days ago]
A recurrent southern hemisphere coronal hole (CH665) will likely rotate into an Earth facing position on April 26-27.
Long distance low and medium frequency (below 2 MHz) propagation along paths north of due west over upper middle latitudes is poor. Propagation on long distance northeast-southwest paths is poor to fair.
The geomagnetic field is expected to be quiet to unsettled on April 23-25.
| Coronal holes (1) | Coronal mass ejection (2) | M and X class flares (3) |
1) Effects from a coronal hole could reach Earth within the
next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.
Green: 0-30% probability, Yellow: 30-70% probability, Red: 70-100% probability.
(Click on image for 2K resolution) Compare to the previous day's image. 0.5K image
When available the active region map has a coronal hole polarity overlay where red (pink) is negative and blue is positive.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SWPC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SWPC or where SWPC has observed no spots. SWPC active region numbers in the table below and in the active region map above are the historic SWPC/USAF numbers.
| Active region | Date numbered detected |
Spot count | Location at midnight | Area | Classification | SDO / HMI 4K continuum image with magnetic polarity overlay |
Comment | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| SWPC | Magnetic (SDO) |
SWPC | STAR | Current | Previous | ||||||
| 2K | 1K | ||||||||||
| 12321 | 2015.04.10 2015.04.11 |
1 | 1 | N07W73 | 0030 | HSX | AXX |
 |
 |
area: 0002 location: N13W73 SWPC data is for AR S4367 |
|
| S4367 | 2015.04.11 | 1 | 1 | N08W71 | 0020 | HRX |
 |
 |
|||
| 12326 | 2015.04.11 2015.04.16 |
N15W69 |
 |
||||||||
| 12324 | 2015.04.13 2015.04.14 |
14 | 19 | 12 | N19W47 | 0165 | CAI | CAI |
 |
 |
|
| 12325 | 2015.04.13 2015.04.14 |
7 | 21 | 11 | N06W39 | 0205 | CAO | DKO |
 |
 |
area: 0360 location: N05W38 |
| S4383 | 2015.04.16 | 13 | 2 | S10W15 | 0025 | BXO |
 |
 |
|||
| 12327 | 2015.04.16 2015.04.17 |
3 | 16 | 9 | S10E03 | 0090 | HSX | CSI |
 |
 |
area: 0170 |
| S4389 | 2015.04.17 | 3 | 2 | S22E10 | 0010 | BXO |
 |
 |
|||
| 12331 | 2015.04.17 2015.04.21 |
15 | 26 | 14 | S10W04 | 0040 | DAC | DAI |
 |
 |
area: 0180 |
| 12329 | 2015.04.17 2015.04.19 |
8 | S08W93 | 0050 | CRO |
 |
rotated out of view | ||||
| 12332 | 2015.04.18 2015.04.21 |
5 | 4 | 2 | S13W31 | 0020 | CRO | DRO |
 |
 |
area: 0030 |
| 12330 | 2015.04.19 2015.04.20 |
4 | 2 | N15E04 | 0010 | AXX |
 |
 |
|||
| S4398 | 2015.04.19 | 11 | 5 | N10W12 | 0030 | CRO |
 |
 |
|||
| S4400 | 2015.04.20 | 6 | 3 | N08E19 | 0015 | BXO | images/AR_S4400_20150422_2345.png | images/AR_S4400_20150421_2345.png | |||
| S4404 | 2015.04.21 | 4 | 2 | N08E52 | 0010 | BXO |
 |
 |
|||
| 12333 | 2015.04.21 2015.04.22 |
1 | 4 | 1 | N19E62 | 0030 | HRX | HAX |
 |
 |
area: 0060 location: N20E65 |
| S4406 | 2015.04.21 | 2 | S11W39 | 0006 | BXO |
 |
 |
||||
| S4407 | 2015.04.22 | 3 | 2 | N18E40 | 0010 | BXO |
 |
||||
| S4408 | 2015.04.22 | 14 | 6 | N20W67 | 0100 | DAI |
 |
beta-gamma | |||
| S4409 | 2015.04.22 | 1 | 1 | S03E42 | 0003 | AXX |
 |
||||
| S4410 | 2015.04.22 | 2 | N23E13 | 0005 | BXO |
 |
|||||
| Total spot count: | 54 | 155 | 75 | ||||||||
| Sunspot number: | 134 | 345 | 235 | (total spot count + 10 * number of spotted regions) | |||||||
| Weighted SN: | 88 | 199 | 119 | (Sum of total spot count + classification weighting for each AR. Classification weighting: X=0, R=3, A/S=5, H/K=10) | |||||||
| Relative sunspot number (Wolf number): | 80 | 121 | 129 | k * (sunspot number). k = 0.6 for SWPC, k = 0.35 for MSN 2K, k = 0.55 for MSN 1K (MSN=Magnetic Sunspot Number) | |||||||
| Month | Average solar flux | International sunspot number (WDC-SILSO) |
Smoothed sunspot number | Average
ap (3) |
|
|---|---|---|---|---|---|
| Measured | 1 AU | ||||
| 2013.11 | 148.3 | 145.1 | 77.6 | 75.4 (+0.4) | 5.68 |
| 2013.12 | 147.7 | 143.1 | 90.3 | 76.0 (+0.6) | 4.68 |
| 2014.01 | 157.4 | 152.4 | 81.8 | 77.3 (+1.3) | 5.44 |
| 2014.02 | 170.3 (cycle peak) |
166.3 | 102.3 (cycle peak) | 78.4 (+1.1) | 10.70 |
| 2014.03 | 149.9 | 148.5 | 91.9 | 80.8 (+2.4) | 4.88 |
| 2014.04 | 143.9 | 144.8 | 84.7 | 81.9 (+1.1) (likely solar max) |
7.88 |
| 2014.05 | 129.7 | 132.9 | 75.2 | 80.5 (-1.4) | 5.75 |
| 2014.06 | 122.0 | 125.8 | 71.0 | 79.7 (-0.8) | 6.72 |
| 2014.07 | 137.4 | 141.8 | 72.5 | 78.6 (-1.1) | 4.50 |
| 2014.08 | 124.7 | 127.9 | 74.7 | 75.6 (-3.0) | 7.71 |
| 2014.09 | 146.6 | 148.1 | 87.6 | 70.9 (-4.7) | 9.78 |
| 2014.10 | 153.4 | 152.9 | 60.6 | (67.3 projected, -3.6) | 8.96 |
| 2014.11 | 154.8 | 151.4 | 70.1 | (64.7 projected, -2.6) | 9.33 |
| 2014.12 | 158.7 | 153.8 | 78.0 | (62.4 projected, -2.3) | 11.24 |
| 2015.01 | 141.9 | 137.3 | 67.0 | (60.2 projected, -2.2) | 9.46 |
| 2015.02 | 129.1 | 126.0 | 44.8 | (58.4 projected, -1.8) | 9.92 |
| 2015.03 | 125.9 | 124.6 | 38.4 | (56.1 projected, -2.3) | 16.14 |
| 2015.04 | (132.9) | 57.5 (2A) / 78.4 (2B) / 85.3 (2C) | (53.4 projected, -2.7) | (12.1) | |
1) Running average based on the daily 20:00 UTC observed solar flux value at
2800 MHz.
2A) Current impact on the monthly sunspot number based on the Boulder (NOAA/SWPC)
sunspot number (accumulated daily sunspots / month days). The official WDC-SILSO
international sunspot number is typically 30-50% lower. 2B) Boulder SN current
month average to date. 2C) STAR SDO 1K Wolf number 30 day average.
3) Running average based on the quicklook and definitive Potsdam WDC ap
indices. Values in red are based on the definitive
international
GFZ Potsdam
WDC
ap indices.
This report has been prepared by Jan Alvestad. It is based on the analysis of data from whatever sources are available at the time the report is prepared. All time references are to the UTC day. Comments and suggestions are always welcome.
SDO images are courtesy of NASA/SDO and the AIA, EVE, and HMI science teams.
