Last major update issued on August 18, 2014 at 20:20 UTC.

[Solar and geomagnetic data - last month (updated daily)]
[Solar wind and electron fluence charts (updated daily)]
[Solar cycles 23-24 (last update August 1, 2014)] [Cycle 24 progress (last update August 13, 2014) ]
[Solar cycles 1-20]
[Graphical comparison of cycles 21, 22, 23 and 24 (last update August 1, 2014)]
[Graphical comparison of cycles 10, 12, 13, 14, 16 and 24 (last update August 1, 2014)]
[Historical solar and geomagnetic data charts 1954-2006 (last update April 5, 2007)]
[Archived reports since January 2003 (last update August 9, 2014)]

[POES auroral activity level October 2009 - December 2012]
[Solar polar fields vs solar cycles - updated July 18, 2014]
[Presentations: 3rd SSN Workshop, Tucson, 2013 (pdf) / 4th SSN Workshop, Locarno, 2014]

Recent activity

The geomagnetic field was quiet on August 17. Solar wind speed at SOHO ranged between 279 and 345 km/s.

Solar flux at 20h UTC on 2.8 GHz was 115 (increasing 24.9 over the last solar rotation). The 90 day 10.7 flux at 1 AU was 130.1. The Potsdam WDC planetary A index was 5 (STAR Ap - based on the mean of three hour interval ap indices: 5.0). Three hour interval K indices: 21122201 (planetary), 21123312 (Boulder).

The background x-ray flux is at the class B3 level.

At the time of counting spots (see image time), spots were observed in 9 active regions using 2K resolution (SN: 174) and 8 active regions using 1K resolution (SN: 124) SDO images on the visible solar disk.

Region 12135 [N15W84] decayed slowly and quietly.
Region 12139 [N13W12] decayed slowly and quietly.
Region 12141 [N17E21] was quiet and stable.
Region 12142 [N09E20] was quiet and stable.
Region 12143 [S04E15] reemerged with a few spots.
Region 12144 [S18W60] was quiet and stable.
Region 12146 [N08E63] was quiet and stable.
New region 12147 [S10E76] rotated into view.

Spotted regions not numbered (or interpreted differently) by SWPC:
S3741 [N13E38] was quiet and stable.

C2+ Flares (GOES):

Magnitude Peak time (UTC) Location AR


Coronal mass ejections (CMEs)

August 15: A CME was observed following a filament eruption in the central part of the solar disk. The CME could reach Earth on August 18 or 19.
August 16-17
: No obviously Earth directed CMEs were observed in LASCO and STEREO imagery.

Coronal holes

[Coronal hole history (since October 2002)]
[Compare today's report to the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago]

No obvious coronal holes are currently in or near Earth facing positions.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along paths north of due west over upper middle latitudes is fair. Propagation on long distance northeast-southwest paths is poor.

Forecast

The geomagnetic field is expected to be quiet to unsettled on August 18-19 due to possible CME effects and quiet on August 20.

Coronal holes (1) Coronal mass ejection (2) M and X class flares (3)


1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-30% probability, Yellow: 30-70% probability, Red: 70-100% probability.

Active solar regions

(Click on image for 2K resolution) Compare to the previous day's image. 0.5K image

When available the active region map has a coronal hole polarity overlay where red (pink) is negative and blue is positive.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SWPC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SWPC or where SWPC has observed no spots. SWPC active region numbers in the table below and in the active region map above are the historic SWPC/USAF numbers.

Active region Date numbered
detected
Spot count Location at midnight Area Classification SDO / HMI 4K continuum
image with magnetic polarity overlay
Comment
SWPC Magnetic
(SDO)
SWPC STAR Current Previous
2K 1K
12135 2014.08.06 2 2 1 N16W87 0060 HAX HAX
12139 2014.08.10
2014.08.11
13 29 14 N14W14 0100 CAI CAI
12144 2014.08.11
2014.08.14
5 6 3 S17W61 0220 DSI DHO area: 0470
12143 2014.08.13
2014.08.14
3 10 4 S05E19 0030 CRO CRO
12142 2014.08.13
2014.08.14
  1 1 N05E12 0004   AXX location: N09E20
12141 2014.08.13
2014.08.14
13 29 17 N16E18 0110 ESO ESI area: 0200
S3734 2014.08.13       N22W26           plage
S3736 2014.08.14       S20W23           plage
12145 2014.08.14
2014.08.15
1     S27W13 0010 AXX     spotless
S3738 2014.08.15       N16W48           plage
12146 2014.08.16 2 3 2 N08E63 0080 HAX HAX area: 0200
S3741 2014.08.16   1   N13E38 0001   AXX
S3742 2014.08.16       N26W29
S3743 2014.08.16       S21W31
12147 2014.08.17 2 3 2 S10E76 0030 CAO CAO   area: 0090
Total spot count: 41 84 44
Sunspot number: 121 174 124  (total spot count + 10 * number of spotted regions)
Weighted SN: 74 122 82  (Sum of total spot count + classification weighting for each AR. Classification weighting: X=0, R=3, A/S=5, H/K=10)
Relative sunspot number (Wolf number): 73 61 68 k * (sunspot number). k = 0.6 for SWPC, k = 0.35 for MSN 2K, k = 0.55 for MSN 1K (MSN=Magnetic Sunspot Number)

Monthly solar cycle data

Month Average solar flux International sunspot number
(WDC-SILSO)
Smoothed sunspot number Average ap
(3)
Measured 1 AU
2013.04 124.8 125.9 72.4 57.9 (+0.4) 5.40
2013.05 131.4 134.3 78.7 59.9 (+2.0) 9.73
2013.06 110.1 113.7 52.5 62.6 (+2.7) 12.60
2013.07 115.5 119.3 57.0 65.5 (+2.9) 9.47
2013.08 114.6 118.3 66.0 69.0 (+3.5) 8.27
2013.09 102.6 103.7 36.9 73.1 (+4.1) 5.23
2013.10  132.1 131.2 85.6 75.0 (+1.9) 7.71
2013.11  148.3 145.1 77.6 75.4 (+0.4) 5.68
2013.12 147.7 143.1 90.3 76.0 (+0.6) 4.68
2014.01 157.4 152.4 81.8 77.3 (+1.3) 5.44
2014.02 170.3
(cycle peak)
166.3 102.3 (cycle peak) (78.1 projected, +0.8) 10.70
2014.03 149.9 148.5 91.9 (79.0 projected, +0.9) 4.88
2014.04 143.9 144.8 84.7 (78.1 projected, -0.9) 7.88
2014.05 129.7 132.9 75.2 (75.6 projected, -2.5) 5.75
2014.06 122.0 125.8 71.0 (72.9 projected, -2.7) 6.72
2014.07 137.4 141.8 72.5 (69.9 projected, -3.0) 4.5
2014.08 125.1 (1)   62.2 (2A) / 113.5 (2B) / 72.1 (2C) (66.5 projected, -3.4) (5.9)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2A) Current impact on the monthly sunspot number based on the Boulder (NOAA/SWPC) sunspot number (accumulated daily sunspots / month days). The official WDC-SILSO international sunspot number is typically 30-50% lower. 2B) Boulder SN current month average to date. 2C) STAR SDO 1K Wolf number 30 day average.
3) Running average based on the quicklook and definitive Potsdam WDC ap indices. Values in red are based on the definitive international GFZ Potsdam WDC ap indices.

This report has been prepared by Jan Alvestad. It is based on the analysis of data from whatever sources are available at the time the report is prepared. All time references are to the UTC day. Comments and suggestions are always welcome.

SDO images are courtesy of NASA/SDO and the AIA, EVE, and HMI science teams.
