Recent activity

The geomagnetic field was quiet on January 2. Solar wind speed ranged between 344 and 471 km/s. An unexpected solar wind disturbance began after 17h UTC, solar wind parameters indicate a CME origin.

Solar flux measured at 20h UTC on 2.8 GHz was 134.7 (decreasing 16.4 over the last solar rotation). The planetary A index was 4 (STAR Ap - based on the mean of three hour interval ap indices: 3.9). Three hour interval K indices: 00002122 (planetary), 10113222 (Boulder).

The background x-ray flux is at the class B4 level.

At midnight UTC the visible solar disk had 8 spotted regions (in 2K resolution SDO images).

Region 11388 [S23W08] was quiet and stable.
Region 11389 [S16E05] added a few spots and has reversed polarities. Note that SWPC includes region S1401 in this region.
Region 11390 [N11W30] developed many new spots as new flux emerged.
New region 11391 [N12E82] rotated partly into view at the northeast limb. The leader penumbra is large and extends 4 degrees latitudinally. M flares are posssible.

Spotted regions not reported (or interpreted differently) by NOAA/SWPC:
[S1392] rotated into view at the southeast limb on December 23, slow decay has been observed since Dec.30. Location at midnight: S18W55
[S1401] rotated into view at the southeast limb on December 28 and developed significantly in the central and trailing spot sections on Dec.29-31. The leading spot section decayed on January 1. Quick decay was observed on January 2, particuarly in the trailing spot section. Location at midnight: S23E10. Flares: C1.6 at 05:28, C1.5 at 07:24 UTC.
[S1406] emerged in the northeast quadrant on January 2. Location at midnight: N10E43
[S1407] emerged in the northeast quadrant on January 2. Location at midnight: N21E24

The most significant event of the day was a long duration C2.4 event peaking at 15:24 UTC from a source just behind the northwest limb. This event was associated with a minor proton flux enhancement.

Coronal mass ejections (CMEs)

December 31 - January 2: No obviously Earth directed CMEs were observed in LASCO and STEREO imagery.

Coronal holes

Coronal hole history (since October 2002)
Compare today's report to the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A recurrent trans equatorial coronal hole (CH491) will likely rotate into an Earth facing position on January 4-5.

The above coronal hole map is based on a new method where coronal holes are detected automatically. The method may need some fine tuning, however, it has significant advantages over detecting coronal holes manually. The main improvement is the ability to detect coronal holes at and just beyond the solar limbs. Early results using this method for SDO images over a span of several weeks indicate a good match between coronal holes observed over the visible disk and their extent and position at the east and west limbs. Note that the polar coronal holes are easily detected using the new method, the extent and intensity of both holes are consistent with other data sources.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along paths north of due west over high and upper middle latitudes is poor. Propagation on long distance northeast-southwest paths is fair to good.

Forecast

The geomagnetic field is expected to be quiet to active on January 3 and quiet on January 4-6. A high speed stream from CH491 could cause some unsettled and active intervals on January 7-8.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)


1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Active solar regions

Click on image for higher resolution image) Compare to the previous day's image

When available the active region map has a coronal hole polarity overlay where red (pink) is negative and blue (blue-green) is positive.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SWPC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SWPC or where SWPC has observed no spots. SWPC active region numbers in the table below and in the active region map above are the historic SWPC/USAF numbers.

Active region Date numbered
detected
Spot count Location at midnight Area Classification SDO / HMI 4K continuum
image with magnetic polarity overlay
Comment
SWPC STAR SDO SWPC STAR Current Previous
11386 2011.12.22
2011.12.23
1   S17W57 0050 HSX       spotless

location: S16W59

SWPC includes region S1392

S1392 2011.12.23   3 S18W55 0080   CSO
11388 2011.12.26
2011.12.27
1 5 S24W14 0060 HSX CSO area: 0120

location: S23W08

11389 2011.12.27
2011.12.28
21 5 S22E08 0330 FKC CHO reversed polarities

area: 0320

location: S16E05

SWPC includes region S1401

S1400 2011.12.27     N17W36         plage
S1401 2011.12.28   32 S23E10 0130   EAO
11390 2011.12.28 9 15 N10W29 0010 BXO DRI location: N11W30

area: 0040

S1403 2011.12.30     N24W25           plage
S1404 2011.12.30     N11W47           plage
S1405 2011.12.31     N15E01           plage
11391 2012.01.02 1 6 N13E81 0120 HSX DHO   location: N12E82

area: 0550

S1406 2012.01.02   1 N10E43 0000   AXX
S1407 2012.01.02   11 N21E24 0020   BXO
Total spot count: 33 78
Sunspot number: 83 158  (total spot count + 10 * number of spotted regions)
Weighted penumbral SN: 58 116  (Sum of total spot count + classification weighting for each AR. Classification weighting: X=0, R=3, A/S=5, H/K=10)
Relative sunspot number (Wolf number): 50 71  k * (sunspot number). k = 0.6 for SWPC. k = 0.45 (changed from 0.33 on Nov.1) for STAR SDO

Monthly solar cycle data

Month Average measured solar flux International sunspot number (SIDC) Smoothed sunspot number Average ap
(3)
2008.07 65.7 (SF minimum) 0.5 2.8 (-0.4)
2008.12 69.2 0.8 1.7 (-)
sunspot minimum
3.25
2010.10 81.6 23.5 23.2 (+3.6) 6.07 / 6.27
2010.11 82.5 21.5 26.5 (+3.3) 4.80 / 5.50
2010.12 84.2 14.4 28.8 (+2.3) 3.41 / 4.35
2011.01 83.6 19.1 31.0 (+2.2) 4.32 / 5.51
2011.02 94.6 29.4 33.4 (+2.4) 5.41 / 6.44
2011.03 115.0 56.2 36.9 (+3.5) 7.79 / 8.18
2011.04 112.6 54.4 41.8 (+4.9) 9.71 / 8.83
2011.05 95.8 41.6 47.6 (+5.8) 9.18 / 8.94
2011.06 95.8 37.0 53.2 (+5.6) 8.96 / 8.06
2011.07 94.2 43.9 (57.8 projected, +4.6) 9.14 / 8.16
2011.08 101.7 50.6 (62.0 projected, +4.2) 8.16 / 7.26
2011.09 133.8 78.0 (65.3 projected, +3.3) 12.80 / 12.27
2011.10 137.3 88.0 (68.8 projected, +3.5) 7.52
2011.11 153.5 96.7 (73.2 projected, +4.3) 4.58
2011.12 141.3 73.0 (78.6 projected, +5.5) 3.32
2012.01 132.4 (1) 4.3 (2A) / 66.5 (2B) (84.4 projected, +5.8) (3.94)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2A) Current impact on the monthly sunspot number based on the Boulder (NOAA/SWPC) sunspot number (accumulated daily sunspots / month days). The official SIDC international sunspot number is typically 30-50% lower. 2B) Month average to date.
3) Running average based on the preliminary daily SWPC ap indices. Values in red are based on the official NGDC ap indices.

This report has been prepared by Jan Alvestad. It is based on analysis of data from whatever sources are available at the time the report is prepared. All time references are to the UTC day. Comments and suggestions are always welcome.

SDO images are courtesy of NASA/SDO and the AIA, EVE, and HMI science teams.
