Recent activity

The geomagnetic field was quiet on February 18. Solar wind speed ranged between 337 and 436 km/s, after 09h UTC weakly under the influence of a high speed stream from CH393.

Solar flux measured at 20h UTC on 2.8 GHz was 85.0. The planetary A index was 4 (STAR Ap - based on the mean of three hour interval ap indices: 3.5). Three hour interval K indices: 00002221 (planetary), 00012330 (Boulder).

The background x-ray flux is at the class A5 level.

At midnight there was 1 spotted region on the visible solar disk.

Region 11049 was quiet and stable.

Coronal mass ejections (CMEs)

February 16-18: No obvious Earth directed CMEs were observed in LASCO images.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report to the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A new coronal hole (CH393) in the southern hemisphere was in an Earth facing position on February 15.

Processed SOHO/EIT 195 image at 15.36 UTC on February 18. The darkest areas on the solar disk are likely coronal holes.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along paths north of due west over high and upper middle latitudes is poor. Propagation on long distance northeast-southwest paths is poor.

Forecast

The geomagnetic field is expected to be quiet on February 19-22.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)



1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SWPC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SWPC or where SWPC has observed no spots. SWPC active region numbers in the table below and in the active region map above are the historic SWPC/USAF numbers.

Active region Date numbered SWPC
spot
count
STAR
spot
count
Location at midnight Area SWPC
Classification
Comment
11046 2010.02.07     N22W71     plage
11047 2010.02.08     S18W61     plage
11048 2010.02.13     N20E11     plage
11049 2010.02.17 7 11 S19W13 0060 DAO
Total spot count: 7 11
SSN: 17 21

Monthly solar cycle data

Month Average measured solar flux International sunspot number (SIDC) Smoothed sunspot number Average ap
(3)
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.

2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2008.07 65.7 0.5 2.8 (-0.4)
2008.12 69.2 0.8 1.7 (-)
sunspot minimum
3.25
2009.01 69.8 1.3 1.8 (+0.1) 3.70
2009.02 70.0 1.4 1.9 (+0.1) 4.68
2009.03 69.2 0.7 2.0 (+0.1) 4.85
2009.04 69.7 1.2 2.2 (+0.2) 4.52
2009.05 70.5 2.9 2.3 (+0.1) 4.75
2009.06 68.6 2.6 2.7 (+0.4) 5.22
2009.07 68.2 3.5 3.6 (+0.9) 5.49 / 4.55
2009.08 67.3 0.0 (5.0 predicted, +1.4) 5.70 / 4.89
2009.09 70.5 4.2 (6.8 predicted, +1.8) 3.88 / 3.61
2009.10 72.6 4.6 (8.7 predicted, +1.9) 3.66 / 3.56
2009.11 73.6 4.2 (10.7 predicted, +2.0) 2.45 / 2.63
2009.12 76.7 10.6 (12.9 predicted, +2.2) 1.41 / 1.92
2010.01 81.1 13.1 (15.4 predicted, +2.5) 2.93 / 3.07
2010.02 86.1 (1) 22.1 (2) (18.3 predicted, +2.9) (5.21)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SWPC) sunspot number. The official international sunspot number is typically 30-50% lower.
3) Running average based on the daily SWPC ap indices. Values in red are based on official NGDC ap indices.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
