Solar Terrestrial Activity Report

Last major update issued on April 9, 2010 at 03:25 UTC.

[Solar and geomagnetic data - last month (updated daily)]
[Solar wind and electron fluence charts (updated daily)
[Solar cycles 21-23 (last update October 4, 2007)]
[Solar cycles 1-20]
[Graphical comparison of cycles 21, 22 and 23 (last update October 4, 2007)]
[Graphical comparison of cycles 2, 10, 13, 17, 20 and 23 (last update October 4, 2007)]
[Historical solar and geomagnetic data charts 1954-2006 (last update April 5, 2007)]
[Archived reports (last update April 2, 2010)]

Recent activity

The geomagnetic field was quiet to active on April 8. Solar wind speed ranged between 532 and 584 km/s under the influence of a high speed stream from CH398.

Solar flux measured at 20h UTC on 2.8 GHz was 75.7. The planetary A index was 11 (STAR Ap - based on the mean of three hour interval ap indices: 10.8). Three hour interval K indices: 42222123 (planetary), 43232113 (Boulder).

The background x-ray flux is at the class A3 level.

At midnight there was 1 spotted region on the visible solar disk.

Region 11061 decayed slowly and was quiet.

Coronal mass ejections (CMEs)

April 6-7: No obvious Earth directed CMEs were observed in LASCO or STEREO images.
April 8: LASCO observed a faint full halo CME following a long duration B3.7 event in region 11061 peaking at 03:25 UTC.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report to the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

No obvious coronal holes are currently in or near Earth facing locations.

Processed SOHO/EIT 195 image at 20:36 UTC on April 8. The darkest areas on the solar disk are likely coronal holes.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along paths north of due west over high and upper middle latitudes is very poor. Propagation on long distance northeast-southwest paths is fair.

Forecast

The geomagnetic field is expected to be quiet to unsettled on April 9 and quiet on April 10. Some unsettled and active intervals are possible on April 11 and 12 due to the passage of the CME observed on April 8.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)



1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Active solar regions (Recent map)

Compare to the previous day's image

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SWPC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SWPC or where SWPC has observed no spots. SWPC active region numbers in the table below and in the active region map above are the historic SWPC/USAF numbers.

Active region Date numbered SWPC
spot
count
STAR
spot
count
Location at midnight Area SWPC
Classification
Comment
11060 2010.04.03 1   N25E00 0000 AXX
11061 2010.04.05 2 1 N14W52 0050 CSO classification was HSX at midnight
S760 2010.04.07     N12W32     plage
Total spot count: 3 1
SSN: 23 11

Monthly solar cycle data

Month Average measured solar flux International sunspot number (SIDC) Smoothed sunspot number Average ap
(3)
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.

2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2008.07 65.7 (SF minimum) 0.5 2.8 (-0.4)
2008.12 69.2 0.8 1.7 (-)
sunspot minimum
3.25
2009.02 70.0 1.4 1.9 (+0.1) 4.68
2009.03 69.2 0.7 2.0 (+0.1) 4.85
2009.04 69.7 1.2 2.2 (+0.2) 4.52
2009.05 70.5 2.9 2.3 (+0.1) 4.75
2009.06 68.6 2.6 2.7 (+0.4) 5.22
2009.07 68.2 3.5 3.6 (+0.9) 5.49 / 4.55
2009.08 67.3 0.0 4.8 (+1.2) 5.70 / 4.89
2009.09 70.5 4.2 6.1 (+1.3) 3.88 / 3.61
2009.10 72.6 4.6 (7.4 predicted, +1.3) 3.66 / 3.56
2009.11 73.6 4.2 (8.9 predicted, +1.5) 2.45 / 2.63
2009.12 76.7 10.6 (10.8 predicted, +1.9) 1.41 / 1.92
2010.01 81.1 13.1 (12.6 predicted, +1.8) 2.93 / 3.07
2010.02 84.7 18.6 (14.7 predicted, +2.1) 4.15 / 4.61
2010.03 83.4 15.4 (17.1 predicted, +2.4) 4.58
2010.04 77.5 (1) 8.3 (2) (19.4 predicted, +2.3) (21.47)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SWPC) sunspot number. The official international sunspot number is typically 30-50% lower.
3) Running average based on the daily SWPC ap indices. Values in red are based on official NGDC ap indices.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
