The geomagnetic field was quiet to minor storm on July 11. Solar wind speed ranged between 337 and 655 km/s (average speed was 544 km/s, increasing 245 km/s over the previous day) under the influence of a high speed stream from CH277.
Solar flux measured at 20h UTC on 2.8 GHz was 78.5. The planetary A index was 23 (STAR Ap - based on the mean of three hour interval ap indices: 22.6). Three hour interval K indices: 55542222 (planetary), 55543322 (Boulder).
The background x-ray flux is at the class A3 level.
At midnight there was 1 spotted region on the visible solar disk. The solar flare activity level was very low. No C class events were recorded during the day.
Region 10963 decayed and lost several small spots. The region has become magnetically fairly simple structured. C flares are still possible, as is a minor M class flare.
July 9-11: No obvious fully or partly Earth directed CMEs were observed.
history (since late October 2002)
Compare today's report to the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago
The northwesternmost extension of a recurrent coronal hole (CH277) in the southern hemisphere was in an Earth facing position on July 6-7. The northeasternmost extension of the same coronal hole structure may have been in an Earth facing position on July 9-10.
Processed SOHO/EIT 195 image at 21:24 UTC on July 11. The darkest areas on the solar disk are likely coronal holes.
Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is very poor. Propagation on long distance northeast-southwest paths is fair.
Monitoring remarks from a location near N58E06: July 12: There was not much to hear until near LSR. Then a number of stations from Brasil became audible. A few stations from Argentina (best signal from 950 Radio Belgrano) and Paraguay (best signal was that of 1020.06 Radio Ñandutí while 1330 probably had Chaco Boreal AM mixing with a Brazilian station).
The geomagnetic field is expected to be quiet to unsettled on July 12-14 due to effects from CH277.
|Coronal holes (1)||Coronal mass ejections (2)||M and X class flares (3)|
1) Effects from a coronal hole could reach Earth
within the next 5 days. When the high speed stream has arrived the
color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
Compare to the previous day's image.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.
|Active region||Date numbered||SEC
|Location at midnight||Area||Classification||Comment|
|10963||2007.07.07||18||11||S06E28||0370||EKC||classification was EKI at midnight|
|Total spot count:||18||11|
flux at Earth
|International sunspot number||Smoothed sunspot number|
cycle 23 sunspot max.
|2007.01||83.3||16.9||(11.9 predicted, -0.2)|
|2007.02||77.7||10.6||(11.3 predicted, -0.6)|
|2007.03||72.2||4.8||(10.8 predicted, -0.5)|
|2007.04||72.4||3.7||(10.8 predicted, unchanged)|
|2007.05||74.4||11.7||(10.6 predicted, -0.2)|
|2007.06||73.7||12.0||(10.7 predicted, +0.1)|
|2007.07||74.1 (1)||7.0 (2)||(11.0 predicted, +0.3)|
1) Running average based on the
daily 20:00 UTC observed solar flux
value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% lower.
This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
