Last major update issued on January 5, 2007 at 04:25 UTC.
[Solar and
geomagnetic data - last month (updated daily)]
[Solar wind and
electron fluence charts (updated daily)]
[Solar cycles 21-23
(last update November 12, 2006)]
[Solar cycles 1-20]
[Graphical comparison
of cycles 21, 22 and 23 (last update November 12, 2006)]
[Graphical
comparison of cycles 2, 10, 13, 17, 20 and 23 (last update November 12,
2006)]
[Historical solar and
geomagnetic data charts 1954-2005 (last update March 3, 2006)]
[Archived reports
(last update December 18, 2006)]
The geomagnetic field was quiet to active on January 4. Solar wind speed ranged between 566 and 748 km/s (all day average 644 km/s - decreasing 32 km/s compared to the previous day) under the influence of a high speed stream from CH254.
Solar flux measured at 20h UTC on 2.8 GHz was 89.4. The planetary A index was 16 (STAR Ap - based on the mean of three hour interval ap indices: 15.6). Three hour interval K indices: 34442322 (planetary), 34443312 (Boulder).
The background x-ray flux is at the class A4 level.
At midnight there were 3 spotted regions on the visible solar disk. The solar flare activity level was very low. No C class events were recorded during the day.
Region 10933 gained a few small spots while slow decay was observed in
the trailing spot section.
Region 10934 was quiet and stable.
Region 10935 was quiet and stable.
January 2-4: No obvious partly or fully Earth directed CMEs were detected in LASCO imagery.
Coronal hole
history (since late October 2002)
Compare today's report to the situation one solar rotation ago:
28
days ago
27
days ago
26
days ago
A recurrent coronal hole (CH254) in the southern hemisphere was in an Earth facing position on December 30-31.
Processed SOHO/EIT 195 image at 14:24 UTC on January 4. The darkest areas on the solar disk are likely coronal holes.
The geomagnetic field is expected to be quiet to unsettled on January 5 due to a high speed stream from CH254 and mostly quiet on January 6-9.
Coronal holes (1) | Coronal mass ejections (2) | M and X class flares (3) |
1) Effects from a coronal hole could reach Earth
within the next 5 days. When the high speed stream has arrived the
color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96
hours.
3) There is a possibility of either M or X class flares within the next
48 hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
Monitoring has been temporarily suspended (as of January 1, 2007).
Compare to the previous day's image.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.
Active region | Date numbered | SEC spot count |
STAR spot count |
Location at midnight | Area | Classification | Comment |
---|---|---|---|---|---|---|---|
10933 | 2006.12.30 | 4 | 8 | S04E13 | 0220 | DAO | |
10934 | 2006.12.31 | 1 | 3 | N04E11 | 0030 | HSX | |
10935 | 2007.01.03 | 1 | 2 | S06E37 | 0270 | HHX | classification was HSX at midnight, area 0220 |
Total spot count: | 6 | 13 | |||||
SSN: | 36 | 43 |
Month | Average solar flux at Earth |
International sunspot number | Smoothed sunspot number |
---|---|---|---|
2000.04 | 184.2 | 125.5 | 120.8 cycle 23 sunspot max. |
2000.07 | 202.3 | 170.1 | 119.8 |
2001.12 | 235.1 | 132.2 | 114.6 (-0.9) |
2005.11 | 86.3 | 18.0 | 24.9 (-0.6) |
2005.12 | 90.7 | 41.1 | 23.0 (-1.9) |
2006.01 | 83.4 | 15.3 | 20.8 (-2.2) |
2006.02 | 76.5 | 4.9 | 18.6 (-2.2) |
2006.03 | 75.4 | 10.6 | 17.3 (-1.3) |
2006.04 | 89.0 | 30.2 | 17.1 (-0.2) |
2006.05 | 80.9 | 22.2 | 17.3 (+0.2) |
2006.06 | 76.5 | 13.9 | 16.3 (-1.0) |
2006.07 | 75.7 | 12.2 | (15.0 predicted, -1.3) |
2006.08 | 79.0 | 12.9 | (14.9 predicted, -0.1) |
2006.09 | 77.8 | 14.5 | (14.7 predicted, -0.2) |
2006.10 | 74.3 | 10.4 | (13.5 predicted, -1.2) |
2006.11 | 86.3 | 21.5 | (12.1 predicted, -1.4) |
2006.12 | 84.5 | 13.6 | (11.7 predicted, -0.4) |
2007.01 | 86.9 (1) | 4.3 (2) | (11.9 predicted, +0.2) |
1) Running average based on the
daily 20:00 UTC observed solar flux
value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC)
sunspot number. The official international sunspot number is typically
30-50% lower.
This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
