The geomagnetic field was quiet to unsettled on May 20. Solar wind speed ranged between 466 and 558 (all day average 483) km/sec under the influence of a high speed stream from CH225.
Solar flux measured at 20h UTC on 2.8 GHz was 76.2. The planetary A index
was 7 (STAR Ap - based on the mean of three hour interval ap
indices: 7.0).
Three hour interval K indices: 22231222 (planetary), 12241222 (Boulder).
The background x-ray flux is at the class A1 level.
At midnight there were 2 spotted regions on the visible solar disk. The solar flare activity level was very low. No C class events were recorded during the day.
Region 10884 lost penumbra on the trailing spots while the leader spot
matured.
New region 10885 emerged in the southeast quadrant on May 19 and was
numbered the next day by SEC. Slow development was observed on May 20.
May 18-20: No partly or fully Earth directed CMEs were observed in LASCO imagery.
Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago:
28 days ago
27 days ago
26 days ago
A coronal hole (CH225) in the southern hemisphere was in an Earth facing position on May 16-18.
Processed SOHO/EIT 284 image at 01:06 UTC on May 21. The darkest areas on the solar disk are likely coronal holes.
The geomagnetic field is expected to be quiet to unsettled on May 21 due to a high speed stream from CH225 and quiet on May 22-24.
Coronal holes (1) | Coronal mass ejections (2) | M and X class flares (3) |
1) Effects from a coronal hole could reach Earth
within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is poor. Propagation on long distance northeast-southwest paths is poor to fair. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Radio Cristal del Uruguay had the dominant signal tonight, however, Radio Vibración (Venezuela) reached fair signal levels at times. After LSR most of the stations audible were from Argentina.
Compare to the previous day's image.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.
Active region | Date numbered | SEC spot count |
STAR spot count |
Location at midnight | Area | Classification | Comment |
---|---|---|---|---|---|---|---|
10884 | 2006.05.19 | 7 | 6 | S13E33 | 0090 | CSO | |
10885 | 2006.05.20 | 2 | 7 | S12E44 | 0040 | CRO | formerly region S654 classification was DAO at midnight, area 0050 |
Total spot count: | 9 | 13 | |||||
SSN: | 29 | 33 |
Month | Average solar flux at Earth |
International sunspot number | Smoothed sunspot number |
---|---|---|---|
2000.04 | 184.2 | 125.5 | 120.8 cycle 23 sunspot max. |
2000.07 | 202.3 | 170.1 | 119.8 |
2001.12 | 235.1 | 132.2 | 114.6 (-0.9) |
2005.02 | 97.2 | 29.2 | 33.9 (-0.7) |
2005.03 | 89.9 | 24.5 | 33.5 (-0.4) |
2005.04 | 86.0 | 24.2 | 31.6 (-1.9) |
2005.05 | 99.3 | 42.7 | 28.9 (-2.7) |
2005.06 | 93.7 | 39.3 | 28.8 (-0.1) |
2005.07 | 96.4 | 40.1 | 29.1 (+0.3) |
2005.08 | 90.5 | 36.4 | 27.4 (-1.7) |
2005.09 | 91.1 | 21.9 | 25.8 (-1.6) |
2005.10 | 77.0 | 8.5 | 25.5 (-0.3) |
2005.11 | 86.3 | 18.0 | (24.5 predicted, -1.0) |
2005.12 | 90.7 | 41.2 | (21.8 predicted, -2.7) |
2006.01 | 83.4 | 15.4 | (18.7 predicted, -3.1) |
2006.02 | 76.5 | 4.7 | (15.6 predicted, -3.1) |
2006.03 | 75.4 | 10.8 | (13.4 predicted, -2.2) |
2006.04 | 89.0 | 30.2 | (12.7 predicted, -0.7) |
2006.05 | 80.3 (1) | 21.4 (2) | (12.2 predicted, -0.5) |
1) Running average based on the
daily 20:00 UTC observed solar flux
value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC)
sunspot number. The official international sunspot number is typically
30-50% lower.
This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
