Recent activity

The geomagnetic field was quiet to active on June 1. Solar wind speed ranged between 361 and 575 (all day average 478) km/sec, slowly increasing all day due to a high speed stream from CH226.

Solar flux measured at 20h UTC on 2.8 GHz was 77.2. The planetary A index was 13 (STAR Ap - based on the mean of three hour interval ap indices: 12.6).
Three hour interval K indices: 22242243 (planetary), 22243333 (Boulder).

The background x-ray flux is at the class A2 level.

At midnight there was 1 spotted region on the visible solar disk. The solar flare activity level was very low. No C class events were recorded during the day.

Region 10886 decayed slowly and was quiet. The region is rotating over the northwest limb.

Coronal mass ejections (CMEs)

May 30 - June 1: No partly or fully Earth directed CMEs were observed in LASCO imagery.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A recurrent trans equatorial coronal hole (CH226) was in an Earth facing position on May 29-30. Another recurrent coronal hole (CH227) in the northern hemisphere will probably rotate into an Earth facing position on June 4-6.

Processed SOHO/EIT 284 image at 19:06 UTC on May 26. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be quiet to active on June 2-3 due to a high speed stream from CH226 and mostly quiet on June 4-5.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is very poor. Propagation on long distance northeast-southwest paths is fair to good. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Radio Cristal del Uruguay was the dominant  signal tonight. On other frequencies stations from Brazil enjoyed the best propagation with 1220 Rádio Globo heard with a good signal. Frequencies like 1390 and 1400 kHz had several stations from Brazil.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10886 2006.05.23 1 1 N09W78 0030 AXX area was 0010 at midnight
10887 2006.05.26     S13W18     plage
10889 2006.05.27     S01W59     plage
10891 2006.05.30     S14W07     plage
S659 2006.05.31     N04W40     plage
Total spot count: 1 1
SSN: 11 11

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2005.04 86.0 24.2 31.6 (-1.9)
2005.05 99.3 42.7 28.9 (-2.7)
2005.06 93.7 39.3 28.8 (-0.1)
2005.07 96.4 40.1 29.1 (+0.3)
2005.08 90.5 36.4 27.4 (-1.7)
2005.09 91.1 21.9 25.8 (-1.6)
2005.10 77.0 8.5 25.5 (-0.3)
2005.11 86.3 18.0 24.9 (-0.6)
2005.12 90.7 41.2 (22.8 predicted, -2.1)
2006.01 83.4 15.4 (20.1 predicted, -2.7)
2006.02 76.5 4.7 (17.1 predicted, -3.0)
2006.03 75.4 10.8 (15.1 predicted, -2.0)
2006.04 89.0 30.2 (14.4 predicted, -0.7)
2006.05 80.9 22.2 (13.5 predicted, -0.9)
2006.06 77.2 (1) 0.3 (2) (11.4 predicted, -2.1)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% lower.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
