Recent activity

The geomagnetic field was very quiet to quiet on January 8. Solar wind speed ranged between 337 and 413 (all day average 361) km/sec.

Solar flux measured at 20h UTC on 2.8 GHz was 78.2. The planetary A index was 4 (STAR Ap - based on the mean of three hour interval ap indices: 3.5).
Three hour interval K indices: 01222001 (planetary), 11223200 (Boulder).

The background x-ray flux is at the class A1 level.

At midnight there was 1 spotted region on the visible solar disk. The solar flare activity level was very low. No C class events were recorded during the day.

Region 10845 decayed slowly and quietly.

Coronal mass ejections (CMEs)

January 6-8: No obviously fully or partly Earth directed CMEs were observed.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A poorly defined trans equatorial coronal hole (CH204) was in an Earth facing position on January 8.

Processed SOHO/EIT 284 image at 19:06 UTC on January 8. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be mostly quiet on January 9-15 with a possibility of unsettled intervals on January 11-12 due to effects from CH204.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)
Coronal hole indicator CME indicator M and X class flare indicator

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Effects from a CME are likely to be observed at Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is fair to occasionally good. Propagation on long distance northeast-southwest paths is very poor. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Dominant stations tonight: WLAM Lewiston ME and Radio Vibración (Venezuela). Many stations from the easternmost parts of North America had fair signals. The usual stations from Cuba were heard with fair to good signals.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10845 2006.01.06 1 1 N19E44 0040 HAX
S616 2006.01.06     N07W36     plage
S617 2006.01.06     S03W08     plage
Total spot count: 1 1
SSN: 11 11

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2004.11 113.2 43.5 35.3 (-0.6)
2004.12 94.5 17.9 35.2 (-0.1)
2005.01 102.2 31.3 34.6 (-0.6)
2005.02 97.2 29.2 33.9 (-0.7)
2005.03 89.9 24.5 33.5 (-0.4)
2005.04 86.0 24.4 31.6 (-1.9)
2005.05 99.3 42.6 28.9 (-2.7)
2005.06 93.7 39.6 28.8 (-0.1)
2005.07 96.4 39.9 (29.1 predicted, +0.3)
2005.08 90.5 36.4 (27.4 predicted, -1.7)
2005.09 91.1 22.1 (25.4 predicted, -2.0)
2005.10 77.0 8.5 (23.4 predicted, -2.0)
2005.11 86.3 18.0 (21.0 predicted, -2.4)
2005.12 90.7 41.2 (18.2 predicted, -2.8)
2006.01 83.0 (1) 6.8 (2) (15.2 predicted, -3.0)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% lower.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
