The geomagnetic field was inactive to quiet on November 18. Solar wind speed ranged between 273 and 339 (all day average 295) km/sec. A very weak low speed stream from a coronal hole arrived after about 16h UTC.
Solar flux measured at 20h UTC on 2.8 GHz was 101.1. The planetary
index was 4 (STAR Ap - based on the mean of three hour interval ap
Three hour interval K indices: 00112111 (planetary), 00212120 (Boulder).
The background x-ray flux is at the class B1 level.
At midnight there was 1 spotted region on the visible solar disk. The solar flare activity level was moderate. A total of 4 C and 1 M class events was recorded during the day. Region S605 at the northwest limb became quite active and produced a C1.6 flare at 08:08 and a C1.1 flare at 13:11 UTC.
Region 10822 decayed slightly losing spots in the intermediate spot section. Another minor M class flare is possible. Flares: M1.2, C1.2 at 15:27 C5.8 at 23:57 UTC.
November 17-18: No obvious fully or partly Earth directed CMEs were observed.
November 16: A filament eruption was observed in the northwest quadrant near the equator beginning at 13:48 UTC in SOHO EIT images. The peak activity was observed 15-16h UTC and a slow partial halo CME could be seen in LASCO C3 images after 18:42 UTC. This CME spanned about 190 degrees at midnight UTC and could reach Earth.
history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago
A small trans equatorial coronal hole (CH198) was in an Earth facing position on November 16.
Processed SOHO/EIT 284 image at 01:06 UTC on November 19. The darkest areas on the solar disk are likely coronal holes.
The geomagnetic field is expected to be quiet to unsettled on November 19-21. There is a chance a low speed stream from CH198 could arrive on Nov.19, as could the partial CME observed on Nov.16. If any of these arrive we could see unsettled to active conditions during the latter half of Nov.19 and on Nov. 20.
|Coronal holes (1)||Coronal mass ejections (2)||M and X class flares (3)|
1) Effects from a coronal hole could reach Earth
within the next 5 days. When the high speed stream has arrived
the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is fair to good. Propagation on long distance northeast-southwest paths is poor. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Dominant station tonight: WWNN Pompano Beach FL and Radio Vibración (Venezuela). Most of the stations heard were from the easternmost parts of the USA and Canada. WFXJ Jacksonville FL on 930 kHz was a nice surprise.
Compare to the previous day's image.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.
|Active region||Date numbered||SEC
|Location at midnight||Area||Classification||Comment|
classification was FKI at midnight
|Total spot count:||41||25|
flux at Earth
|International sunspot number||Smoothed sunspot number|
cycle 23 sunspot max.
|2005.05||99.3||42.6||(28.9 predicted, -2.7)|
|2005.06||93.7||39.6||(27.3 predicted, -1.6)|
|2005.07||96.4||39.9||(26.1 predicted, -1.2)|
|2005.08||90.5||36.4||(24.3 predicted, -1.8)|
|2005.09||91.1||22.1||(22.2 predicted, -2.1)|
|2005.10||77.0||8.5||(20.2 predicted, -2.0)|
|2005.11||84.6 (1)||16.8 (2)||(17.8 predicted, -2.4)|
1) Running average based on the daily 20:00 UTC observed solar flux
value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% lower.
This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
