Last major update issued on November 16, 2005 at 05:50 UTC.
geomagnetic data - last month (updated daily)]
[Solar wind and electron fluence charts (updated daily)]
[Solar cycles 21-23 (last update November 9, 2005)]
[Solar cycles 1-20]
[Graphical comparison of cycles 21, 22 and 23 (last update November 9, 2005)]
[Graphical comparison of cycles 2, 10, 13, 17, 20 and 23 (last update November 9, 2005)]
[Historical solar and geomagnetic data charts 1954-2004 (last update February 1, 2005)]
[Archived reports (last update November 2, 2005)]
The geomagnetic field was inactive to quiet on November 15. Solar wind speed ranged between 326 and 416 (all day average 360) km/sec.
Solar flux measured at 20h UTC on 2.8 GHz was 100.0. The planetary
index was 4 (STAR Ap - based on the mean of three hour interval ap
Three hour interval K indices: 11222001 (planetary), 22342111 (Boulder).
The background x-ray flux is at the class B1 level.
At midnight there was 1 spotted region on the visible solar disk. The solar flare activity level was moderate. A total of 10 C and 1 M class events were recorded during the day.
Region 10822 changed significantly with the main penumbra becoming huge as two nearby negative polarity areas merged. While there is quite a bit of polarity intermixing no magnetic delta structures were observed at midnight. Further M class flares are possible. Flares: C1.4 at 00:54, C5.2 at 03:05, C2.3 at 08:18, C1.3 at 08:32, C2.3 at 12:05, C1.0 at 12:43, C2.0 at 15:32, C2.1 at 15:40, C1.2 at 15:57, M1.4 at 17:51 and C2.3 at 21:10 UTC.
November 13-15: No obvious fully or partly Earth directed CMEs were observed.
history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago
A coronal hole (CH197) in the southern hemisphere was likely in an Earth facing (potentially geoeffective) position on November 12-13. A small trans equatorial coronal hole (CH198) will be in an Earth facing position on November 16.
Processed SOHO/EIT 284 image at 19:08 UTC on November 15. The darkest areas on the solar disk are likely coronal holes.
The geomagnetic field is expected to be quiet to active on November 16-17 and quiet to unsettled on November 18-19.
|Coronal holes (1)||Coronal mass ejections (2)||M and X class flares (3)|
1) Effects from a coronal hole could reach Earth
within the next 5 days. When the high speed stream has arrived
the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.
Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.
Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is fair. Propagation on long distance northeast-southwest paths is poor. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Dominant station tonight: Radio Vibración (Venezuela) and WWNN Pompano Beach FL. Cuba had a very good night with excellent signals from a number of stations (one example is Radio Reloj on 870 and 950 kHz).
Compare to the previous day's image.
Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.
|Active region||Date numbered||SEC
|Location at midnight||Area||Classification||Comment|
classification was FKI at midnight, area 0900
|Total spot count:||22||34|
flux at Earth
|International sunspot number||Smoothed sunspot number|
cycle 23 sunspot max.
|2005.05||99.3||42.6||(28.9 predicted, -2.7)|
|2005.06||93.7||39.6||(27.3 predicted, -1.6)|
|2005.07||96.4||39.9||(26.1 predicted, -1.2)|
|2005.08||90.5||36.4||(24.3 predicted, -1.8)|
|2005.09||91.1||22.1||(22.2 predicted, -2.1)|
|2005.10||77.0||8.5||(20.2 predicted, -2.0)|
|2005.11||81.8 (1)||11.1 (2)||(17.8 predicted, -2.4)|
1) Running average based on the daily 20:00 UTC observed solar flux
value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% lower.
This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
