Recent activity

The geomagnetic field was quiet to minor storm on December 12. Solar wind speed ranged between 358 and 582 (all day average 452) km/sec.

Solar flux measured at 20h UTC on 2.8 GHz was 93.1. The planetary A index was 22 (STAR Ap - based on the mean of three hour interval ap indices: 22.5)
Three hour interval K indices: 32342553 (planetary), 32343442 (Boulder).

The background x-ray flux is at the class B1 level.

At midnight there were 3 spotted regions on the visible solar disk. The solar flare activity level was low. A single C class event was recorded during the day.

Region 10830 decayed slowly and quietly.
Region 10834 was quiet and stable.
Region 10835 added a few small spots and remains capable of further C class flare production. Flare: C1.1 at 13:38 UTC.

Coronal mass ejections (CMEs)

December 9-11: No obvious partly or fully Earth directed CMEs were observed in incomplete imagery.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

No obvious coronal holes are currently in or near Earth facing positions.

Processed SOHO/EIT 284 image at 13:06 UTC on December 2. The darkest areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be quiet to unsettled on December 12-14.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)
Coronal hole indicator CME indicator M and X class flare indicator

1) Effects from a coronal hole could reach Earth within the next 5 days. When the high speed stream has arrived the color changes to green.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Propagation

Long distance low and medium frequency (below 2 MHz) propagation along east-west paths over high and upper middle latitudes is very poor. Propagation on long distance northeast-southwest paths is poor. Trans Atlantic propagation conditions are normally monitored every night on 1470 kHz. Dominant station tonight: Radio Vibración (Venezuela) with a weak signal. Very few trans-Atlantic stations were audible on other frequencies.

Active solar regions (Recent map)

Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by NOAA/SEC. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots. SEC active region numbers in the table below and in the active region map above are the historic SEC/USAF numbers.

Active region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10830 2005.12.02 1 1 N12W41 0040 HAX
10833 2005.12.09 3   S16W78 0050 CAO spotless
10834 2005.12.09 3 1 S07E51 0030 CAO classification was HAX at midnight, area 0070
10835 2005.12.09 4 11 N18E55 0220 DAO
S612 2005.12.10     S08W12     plage
Total spot count: 11 13
SSN: 51 43

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2004.10 105.9 48.0 35.9 (-1.6)
2004.11 113.2 43.5 35.3 (-0.6)
2004.12 94.5 17.9 35.2 (-0.1)
2005.01 102.2 31.3 34.6 (-0.6)
2005.02 97.2 29.2 33.9 (-0.7)
2005.03 89.9 24.5 33.5 (-0.4)
2005.04 86.0 24.4 31.6 (-1.9)
2005.05 99.3 42.6 28.9 (-2.7)
2005.06 93.7 39.6 (28.1 predicted, -0.8)
2005.07 96.4 39.9 (27.6 predicted, -0.5)
2005.08 90.5 36.4 (25.7 predicted, -1.8)
2005.09 91.1 22.1 (23.6 predicted, -2.1)
2005.10 77.0 8.5 (21.6 predicted, -2.0)
2005.11 86.3 18.0 (19.2 predicted, -2.4)
2005.12 94.0 (1) 23.4 (2) (16.4 predicted, -2.8)

1) Running average based on the daily 20:00 UTC observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (NOAA/SEC) sunspot number. The official international sunspot number is typically 30-50% lower.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and analysis, and partly on data from some of these solar data sources. All time references are to the UTC day. Comments and suggestions are always welcome.
