Recent activity

The geomagnetic field was quiet to minor storm on January 25. Solar wind speed ranged between 621 and 771 km/sec under the influence of a strong coronal stream.

Solar flux measured at 20h UTC on 2.8 GHz was 128.9. The planetary A index was 28 (STAR Ap - based on the mean of three hour interval ap indices: 28.6).
Three hour interval K indices: 44554322 (planetary), 35554312 (Boulder).

The background x-ray flux is at the class B3 level.

At midnight there were 5 spotted regions on the visible disk, 1 of which has not yet been numbered by SEC/NOAA. Solar flare activity was low. A total of 4 C class events were recorded.

Region 10266 continued to lose trailing spot, however, slow development was observed in the leading spots.
Region 10267 decayed slowly and quietly. Flare: C1.2 at 05:13 UTC.
Region 10268 decayed as the trailing positive polarity spot split off from the leading spots. This is a reversed polarity region. Flares: C1.9 long duration event peaking at 08:36 and C4.4 at 18:55 UTC.
Region 10269 was quiet and stable.

Spotted regions not yet numbered by SEC:
[S80] A new region emerged in the southeast quadrant east of region 10269. Location at midnight: S07E38.

Coronal mass ejections (CMEs)

January 23 and 25: No obviously geoeffective CMEs observed.

January 24: A weak partial halo CME was observed in LASCO C2 images early in the day and appears to have been associated with the M1.9 event in region 10266 at 03:27 UTC. The CME could be geoeffective.

Coronal holes

Coronal hole history (since late October 2002)
Compare today's report with the situation one solar rotation ago: 28 days ago 27 days ago 26 days ago

A small trans equatorial coronal hole will likely rotate into a geoeffective position on January 27. Another coronal hole in the northern hemisphere will probably become geoeffective on January 29-30.

Processed SOHO EIT 284 image at 01:06 UTC on January 26. Any black areas on the solar disk are likely coronal holes.

Forecast

The geomagnetic field is expected to be quiet to active until January 27 due to a coronal stream. Quiet to unsettled is expected on January 28-29 with quiet to active likely on January 30-31. Long distance medium wave (AM) band propagation along east-west paths over high and upper middle latitudes is very poor.

Coronal holes (1) Coronal mass ejections (2) M and X class flares (3)
Coronal hole indicator CME indicator M and X class flare indicator

1) Effects from a coronal hole could reach Earth within the next 5 days.
2) Material from a CME is likely to impact Earth within 96 hours.
3) There is a possibility of either M or X class flares within the next 48 hours.

Green: 0-20% probability, Yellow: 20-60% probability, Red: 60-100% probability.

Active solar regions (Recent map)

Composite image based on a SOHO/MDI continuum image and overlaid by a coronal hole image. Region numbering has been included. Compare to the previous day's image.

Data for all numbered solar regions according to the Solar Region Summary provided by SEC/NOAA. Comments are my own, as is the STAR spot count (spots observed at or inside a few hours before midnight) and data for regions not numbered by SEC or where SEC has observed no spots.

Solar region Date numbered SEC
spot
count
STAR
spot
count
Location at midnight Area Classification Comment
10259 2003.01.14     N10W73     plage
10260 2003.01.15 1 N15W54 0000 AXX actually spotless
10264 2003.01.20     S20W67     plage
10265 2003.01.20     N04W34     plage
10266 2003.01.20 28 21 S21W10 0140 FAI beta-gamma
10267 2003.01.20 13 11 S20E16 0100 EAO
10268 2003.01.21 7 4 N14W29 0130 DAO reversed polarity
10269 2003.01.21 4 3 S08E25 0100 DSO classification was HSX
at midnight, only
negative polarity spots
S80 emerged on
2003.01.25
  1 S07E38 0010 AXX
Total spot count: 53 40
SSN: 103 90

Monthly solar cycle data

Month Average solar
flux at Earth
International sunspot number Smoothed sunspot number
2000.04 184.2 125.5 120.8
cycle 23 sunspot max.
2000.07 202.3 170.1 119.8
2001.12 235.1 132.2 114.6 (-0.9)
2002.01 226.6 114.1 113.5 (-1.1)
2002.02 205.0 107.4 114.6 (+1.2)
2002.03 179.5 98.4 113.3 (-1.3)
2002.04 189.8 120.7 110.5 (-2.9)
2002.05 178.4 120.8 108.8 (-1.7)
2002.06 148.7 88.3 106.2 (-2.6)
2002.07 173.5 99.6 (102.1 predicted, -4.1)
2002.08 183.6 116.4 (98.5 predicted, -3.6)
2002.09 175.8 109.6 (95.5 predicted, -3.0)
2002.10 167.0 97.5 (92.0 predicted, -3.5)
2002.11 168.7 95.0 (86.7 predicted, -5.3)
2002.12 157.2 81.6 (82.4 predicted, -4.3)
2003.01 149.0 (1) 125.1 (2) (79.4 predicted, -3.0)

1) Running average based on the daily 20:00 UT observed solar flux value at 2800 MHz.
2) Unofficial, accumulated value based on the Boulder (SEC/NOAA) sunspot number. The official international sunspot number is typically 25-45% less.

This report has been prepared by Jan Alvestad. It is based partly on my own observations and interpretations, and partly on data from sources noted in solar links. All time references are to the UTC day. Comments and suggestions are always welcome.
